seagate Dysk IronWolf Pro 16TB SATA ST16000NE000

IronWolf NASSeagate IronWolf™ Pro drives (up to 16TB) include AgileArray technology for drive balance, RAID optimization with error recovery control, and power management on commercial and enterprise NAS enclosures up to 24 bays. These drives are purpose-built for creative professionals and small- to medium-sized businesses, and offer IronWolf Health Management (on compatible systems) for dependable drive health monitoring. Enjoy extra peace of mind knowing your digital assets are protected with a Rescue Data Recovery Plan (HDD Data Recovery) in place.• Compatible with 1- to 24-bay network attached storage (NAS) servers, creative pro NAS, media server, personal cloud storage device Features 24x7 performance NAS hard drive 2TB/4TB/6TB/8TB/10TB/12TB/14TB/16TB Fastest hard drive delivers 7200RPM spin speed along with sustained data rates up to 250MB/s and burst data rates of Gb/s 5-year limited warranty and 2-year Rescue Data Recovery Plan Provides a 300TB/year workload limit, perfect for multi-user environments IronWolf Health Management allows for drive health monitoring through compatible NAS Included in box: Seagate IronWolf Pro Drive Key Advantages Optimized for NAS with AgileArray™. AgileArray is built for dual-plane balancing and RAID optimisation in multi-bay environments with the most advanced power management possible. High performance means no lag times or downtime for users during high traffic time for the NAS. Seagate leads the competition with the highest performance in NAS-class drives. Range of capacities up to 16TB. More capacity options means more choices that will fit within the budget. Seagate provides a scalable solution for any NAS use-case scenario Do more with multi-user environments. Built with a workload rate of 300 TB/ year. Multiple users can confidently upload and download data to the NAS server, knowing it can handle the workload, whether you're a creative professional or small business. IronWolf Health Management. Designed to operate on compatible NAS systems such as Synology, ASUSTOR and Thecus. Populated with supported IronWolf or IronWolf Pro HDDs It improves the overall system reliability by displaying actionable prevention, intervention or recovery options for the user. Built in Rotational Vibration Sensors. RV sensors are built in to mitigate vibration in multi-bay applications making sure there is consistent performance and reliability. 24x7 over the phone support for every IronWolf and IronWolf Pro drive. TECHNICAL SPECIFICATIONS SPECIFICATIONS Standard Model Numbers ST16000NE000 Capacity 16TB Inteface SATA 6Gb/s FEATURES and PERFORMANCE Drive Bays Supported Up to 24-bay Multi-User Technology 300TB/year Rotational Vibration (RV) Sensor yes Hot-Plug Support yes Cache (MB) 256 RELIABILITY Load/Unload Cycles1 600,000 Nonrecoverable Read Errors Rate, Max 1 per 10E15 Power-On Hours 8760 Workload Rate Limit (WRL) 180 Mean Time Between Failures (MTBF, hours) 1,200,000 Limited Warranty (years) 5 PERFORMANCE Spindle Speed (RPM) 7200 Interface Access Speed (Gb/s) 6.0, 3.0, 1.5 Max Sustained Transfer Rate OD (MB/s) 250 Average Latency (ms) 4.16 Interface Ports Single Rotational Vibration @ 10-1500 Hz (rad/s[superscript2]) 12.5 POWER MANAGEMENT Startup Current, Typical (12V, A) 1.8 Average Operating Power (W) 7.3W Idle Average (W) 5.3W Standby Mode/Sleep Mode, Typical (W) 0.8/0.8 Voltage Tolerance, Inc. Noise (5V) ±5% Voltage Tolerance, Inc. Noise (12V) ±10% Reliability Rating @ Full 24×7 Operation (AFR) 0,73% Sector Size (Bytes per Logical Sector) 512E POWER CONSUMPTION Startup Current, Typical (12V, A) 2 Idle Power, Average (W) 5 Average Operating Power (W) 7.6 Standby Mode, Typical (W) 1 Sleep Mode, Typical (W) 1 Power Supply Requirements +12V and +5V ENVIRONMENTAL/TEMPERATURE Operating (ambient, min °C) 5 Operating (drive case, max °C)2 60 Nonoperating (ambient, min °C) -40 Nonoperating (ambient, max °C) 70 ENVIRONMENTAL/SHOCK Shock, Operating, 2ms (Read/Write) (Gs) 50Gs/50Gs Shock, Nonoperating, 1ms and 2ms (Gs) 200 ENVIRONMENTAL/ACOUSTICS Vibration, Nonoperating: 10Hz to 500 Hz (Grms) 2.27 Idle (typical)3 2.8bels Operating (typical) 3.2bels PHYSICAL Height (mm/in) 26.11mm/1.028in Width (mm/in, max) 101.85mm/4.010in Depth (mm/in, max) 146.99mm/5.787in Weight (g/lb) 670g/1.477lb Carton Unit Quantity 20 Cartons per Pallet/Cartons per Layer 40 / 8 1 Seagate recommends validating your configuration with your HBA/RAID controller manufacturer to ensure full capacity capabilities.2 Supports Hot-Plug operation per Serial ATA Revision 2.6 specification.3 Rescue recovery services not available in all countries. Contact your Seagate sales representative for further details. Register an IronWolf Pro drive to activate your 2-year Rescue plan at seagate.com/register.

Typ produktu: dysk twardy
EAN: 8719706008730
Kod producenta: ST16000NE000
Seria: IronWolf Pro NAS
Kształt: 3,5 cala
Pojemność: 16TB
Interfejs: 1x SATA/600
Złącze zasilania: 15-stykowe złącze zasilania
Technika zapisu: CMR (konwencjonalny zapis magnetyczny)
Szybkość transmisji danych: 255 MB/s
Prędkość: 7200 obr/min
Rozmiar sektora: 4 KB z emulacją (512e)
Czas dostępu: 4.16ms
Pamięć podręczna: 256 MB
Głośność: 32dB(A)
: 28dB(A)
Pobór mocy: 7,6 W
: 5W
: 1w
: 1w
MTBF: 1 200 000 godzin
Zatoki na dyski: 24
Funkcja: Ciągła praca 24/7, obsługa NAS, zoptymalizowana pod kątem NAS z AgileArray | Zarządzanie zdrowiem IronWolf | Odzyskiwanie danych ratunkowych Seagate | Czujniki RV
Wymiary: szerokość: 101,85 mm x wysokość: 26,11 mm x głębokość/długość: 146,99 mm
Waga: 670 gramów

Seagate IronWolf Pro ST16000NE000. Rozmiar HDD: 3.5", Pojemność HDD: 16000 GB, Szybkość HDD: 7200 RPM
